Adafruit Feather RP2350 with HSTX Port projects and builds

Why it belongs on the bench

Adafruit Feather RP2350 with HSTX Port product 6000 is the no-PSRAM version of a compact RP2350 development board. It combines 8 MB flash, 520 KB on-chip SRAM, a 22-pin HSTX connector, LiPo charging, STEMMA QT, USB-C, SWD debugging and 29 accessible GPIO in the Feather form factor. The HSTX connector can carry DVI video through Adafruit’s matching adapter, while the catalogue’s audio-reactive synth uses the board’s analog inputs, PDM audio pins and CircuitPython framebuffer support for a complete audiovisual build. Product 6130 is a distinct variant with factory-fitted 8 MB PSRAM; do not assume listings or firmware requirements for one revision apply to the other. Adafruit says product 6000 has shipped with A4-revision RP2350 silicon since 2026-03-20, while the project source predates that change; use the current exact-board CircuitPython build and re-check the guide if Adafruit documents revision-specific behavior. Adafruit listed product 6000 in stock at US$12.50 on 2026-09-22. The board itself does not include the HSTX adapter, FPC cable, display or project controls.
